Product Description:
The LED Grow Light Driver is designed with an IP67 rating, ensuring that it is resistant to dust and water. This makes it suitable for use indoors , providing you with the flexibility to grow your plants wherever you choose.
Whether you are a beginner or an experienced grower, the LED Grow Light Driver is an essential tool to help you achieve the best possible results. It provides a stable power supply to your LED grow light, ensuring that your plants receive the right amount of light to promote healthy growth.
The LED Grow Light Driver is easy to install and use. Simply connect it to your LED grow light and power source, and you're ready to go. It is also energy efficient, helping you to reduce your energy consumption and save money on your electricity bill.
Overall, the LED Grow Light Driver is a must-have for any indoor or outdoor gardening setup. Its compact size, versatile output, and IP67 rating make it a reliable and durable choice for any grower. So if you're looking for a high-quality LED Grow Light Driver, look no further than this product!
Technical Parameters:
| MODEL |
USP-800-54 |
USP-800-54-B |
USP-800-54-BA |
NOTE |
|
INPUT
|
VOLTAGE |
120~277VAC |
120~277VAC |
120~277VAC |
|
| FREQUENCY |
50~60Hz |
50~60Hz |
50~60Hz |
|
| MAXIMUM INPUT CURRENT |
8.2A |
8.2A |
8.2A |
|
| INRUSH CURRENT |
≤80A |
≤80A |
≤80A |
|
| STANDBY POWER CONSUMPTION |
≤3w |
≤3w |
≤3w |
|
| POWER FACTOR |
≧0.98(120Vac) ≧0.98(230Vac) ≧0.97(277Vac) |
≧0.98(120Vac) ≧0.98(230Vac) ≧0.97(277Vac) |
≧0.98(120Vac) ≧0.98(230Vac) ≧0.97(277Vac) |
Full-load |
| THD |
≦6.0%(120Vac) ≦6.0%(230Vac) ≦9.0%(277Vac) |
≦6.0%(120Vac) ≦6.0%(230Vac) ≦9.0%(277Vac) |
≦6.0%(120Vac) ≦6.0%(230Vac) ≦9.0%(277Vac) |
Full-load |
|
OUTPUT
|
VOLTAGE RANGE |
30~56V |
30~56V |
30~56V |
|
| CURRENT RANGE |
Max 16.7A |
0~16.7A |
0~16.7A |
|
| MAXIMUM NO-LOAD VOLTAGE |
≤58V |
≤58V |
≤58V |
|
| EFFICIENCY |
≥90.0% @120Vac ≥92.0% @230Vac ≥93.0% @277Vac |
≥90.0% @120Vac ≥92.0% @230Vac ≥93.0% @277Vac |
≥90.0% @120Vac ≥92.0% @230Vac ≥93.0% @277Vac |
Full-load |
| CURRENT ACCURACY |
±5% |
±5% |
±5% |
The actual≤±3% |
| RIPPLE VOLTAGE |
±1% max 2% |
±1% max 2% |
±1% max 2% |
Full-load
|
| RIPPLE CURRENT |
±5% max 10% |
±5% max 10% |
±5% max 10% |
| TURN ON TIME |
≤2S |
≤2S |
≤2S |
|
LINEAR
ADJUSTMENT RATE
|
±1% |
±1% |
±1% |
|
| LOAD REGULATION |
±3% |
±3% |
±3% |
The actual≤±2% |
|
AUXILIARY
POWER SUPPLY
(OPTIONAL)
|
OUTPUT VOLTAGE |
/ |
/ |
12.8V±10% |
|
| OUTPUT(CURRENT) |
/ |
/ |
300mA±5% |
|
| |
|
|
|
|
✤ Dimming Performance (three-in-one dimming)
| PARAMETER |
LEAST VALUE |
TYPICAL CASE |
CREST VALUE |
NOTE |
|
0-10V DIMMING (OPTIONAL)
|
APPLIED PRESSURE
|
0V
|
0-10V
|
15V
|
Over 15V may cause the internal
components of the power supply to burn out, and the function of the
power supply is abnormal
|
| THE DIMMING RANGE |
8% |
10-100% |
100% |
DIM + comes with an output of 100 uA current |
| PUSH THE DIMMING VOLTAGE |
0.8V |
1-10V |
10V |
DIM + and DIM-no output |
|
RESISTANCE
DIMMING
(OPTIONAL)
|
EXTERNAL LIGHT ADJUSTMENT
RESISTANCE
|
8K Ω
|
0-100KΩ
|
100KΩ
|
90 K Ω above is 100% output
|
| THE DIMMING RANGE |
8% |
10-100% |
100% |
DIM + comes with 100 uA constant flow output |
|
PWM AIMING (SELECTABLE)
|
PWM HIGH LEVEL |
9.5V |
9.6-10V |
10.5V |
Dimmer PWM high level maximum |
| PWM LOW LEVEL |
0V |
0-0.35V |
0.5V |
Dimmer PWM low level maximum |
|
THE PWM DIMMING
FREQUENCY SEGMENT
|
500Hz |
1KHz |
2KHz |
Best job at 1 KHz |
| PWM DUTY CYCLE |
7% |
10-100% |
100% |
DIM + and DIM-no output |
| THE DIMMING RANGE |
8% |
10-100% |
100% |
DIM + comes with 100 uA constant flow output |
| THE DIMMING SHUT DOWN |
TURN OFF THE VOLTAGE |
5% |
6% |
7% |
According to the voltage, PWM, resistance ratio |
| CUT-IN VOLTAGE |
6% |
7% |
8% |
| |
Note: 1. When using PWM or voltage dimming, please note that the dimmer controller is set at 10% to the lowest dimming value, and be set to close below 10%, and the lower limit is not lower than 8%! For other dimming methods, please also refer to this method.
2. When the resistance is used for parallel dimming (parallel light modulation), the number of paralle units is: N, then the resistance for dimming~is: 90 KΩ / N, and the dimming resistance value must be greater than the calculated value, then 8%~100% dimming can be realized.
3. When the dimmer is used for dimming, when 20% of the power is input, the power supply may have slight noise and water ripple phenomenon. At this time, the power supply enters the light load and high efficiency frequency jump mode, which is a normal phenomenon.
Support and Services:
The LED Grow Light Driver is a high-performance driver designed to power LED grow lights for indoor horticulture applications. Our technical support team is available to assist you with any questions or issues you may have with the product, including:
- Installation and setup
- Troubleshooting
- Product compatibility
- Warranty information
- And more
In addition to technical support, we also offer services such as:
- Custom product design and development
- Product testing and certification
- On-site consultation and training
- And more
Our goal is to ensure that our customers have a positive experience with our LED Grow Light Driver and are able to achieve the best possible results with their indoor gardening projects.
